FRAME Uni-directional carbon mainframe and rear triangle, tapered head tube, internal cable routing.
FORK Fox Float 38 Performance Elite, 160mm travel, 44mm offset with Grip X2 damper, tapered steerer.
REAR SHOCK Fox Float X Performance Elite DPS, EVOL LV, 230 x 57.5mm, custom tuned for Whyte
HEADSET FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings.
CASSETTE SRAM XS 1275, T-Type, 10-52T, 12 speed
CHAIN SRAM GX T-Type, 12 speed
CRANKSET Whyte 155mm ISIS arms, SRAM Direct mount 36T chainring, T-Type
SEATPOST KS Vantage, 34.9mm, external 30mm adjustment, with Southpaw remote lever
SADDLE Whyte Custom
HANDLEBAR Race Face Turbine Alloy Bar 35mm, 800mm, 35mm rise
STEM Whyte, 35mm Extension, 35mm Bar Bore
GRIPS Whyte Enduro lock-on
BRAKES FRONT Magura MT7, 1 finger lever, 203mm MDRC 6 bolt rotors
BRAKES REAR Magura MT7, 1 finger lever, 203mm MDRC 6 bolt rotors
REAR HUB DT Swiss Hybrid H1900, 12mm x 148mm Boost spacing, SRAM XD steel driver, 6 Bolt
FRONT HUB DT Swiss Hybrid H1900, 110mm x 15mm Boost, 6 bolt
RIMS DT Swiss Hybrid H1900
SPOKES DT Swiss elemental
FRONT TYRE Maxxis Assegai WT, TR, 29in x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound.
REAR TYRE Maxxis Minion DHR 2 WT, TR, 29in x 2.4in 120TPI, Double Down Casing, 3C MaxxTerra, Dual Compound.
MOTOR Bosch Performance Line CX Gen 5 (85 Nm ) Smart System
MOTOR CONTROLLER Bosch Smart System Mini Remote & System Controller
DISPLAY Bosch Purion 400
BATTERY Bosch PowerTube 800 Wh Battery
